INDUSTRIAL ROLLING SHUTTER
CURTAIN : Constructed using 115*0.9mm/115*1.20mm Galvanized sheet.
BOTTOM PLATE : Aluminum extruded with rubber gasket or MS sheet 3mm mounted with 35x35x5mm angle iron having both side locking system.
BRACKET PLATE : M.S sheet thickness ranges from 3mm to 10mm & size of bracket plate depends upon the height/weight of rolling shutter.
ROLLER DRUM : Fabricated using mild steel tube with the outer diameter and thickness appropriate for the size and application of the rolling shutter.
DOOR LOCKING : Shoot bolts are fitted internally to accept padlock for manually operated rolling shutter only.
HOODS FASCIAS : These are available as optional accessories to suit the application. Hoods are manufactured in house at Gurdeep Rolling Shutter Pvt. Ltd. DKM from 0.9mm galvanized steel sheet.
OPERATION : Manually or electrically operated. Locking is not recommended for electrically operated shutter.
SIDE GUIDES : MS side guides are supplied with brush seal inserted inside on both walls of channel optionally.
